SEM816D

KeySpecification
Advantage
Application

Operating Weight (w. SU blade, Ripper): 18,230kg
Ground Pressure (GB/T 30965): 66.8kPa
Minimum Ground Clearance (Excludes Grouser Height): 410mm

Highly Efficient and Reliable
Outstanding Operator Comfort
Best-in-class Serviceability
C-Frame with manual & fixed-angle adjustments (up to 25°) for different earthmoving application (Angle Blade)
Manual tilt function for a more robust layout (Angle Blade)

Coal
Port
Railway / Highway / Airport
Forestry
Slope terracing (Angle Blade)
Typical dozing, spreading, levelling, cut and fill application (Angle Blade)

Feature
Specification
ProductComparison
Video
Download Brochure

Hydrostatic Drive System

Upgraded hydrostatic system not only leverages Caterpillar automatic, dual path, hydrostatic drive with electronic control technology of the third generation TTT, but also increases efficiency and reliability.
Adopt Rexroth German new generation one case drive pump to combine control valve, track motor, simplified hose line design, continue to increase the reliability.
Caterpillar high pressure hose provides reliability and durability. Caterpillar control technology provides accurate control and high transmission efficiency.
Integrated the hydrostatic oil tank and implement hydraulic oil tank to improve filtrated precision and cooling capability of hydraulic system, increasing reliability and reducing maintenance cost.
Maintenance costs are reduced by 60% when compared competitors with torque converter and transmission and rear axle.
Counter rotation, power turn and infinitely variable speed save lots of time,increasing working efficiency.

Comfortable Operation

Counter rotation—Tracks counter rotate to provide best in class maneuverability.
Powered turn—Machine maintains full power through turns to increase productivity.
Cruise control — Operators can retain previous speed settings which makes operation easily.
Multi-function joystick allows for counter-rotation, powered turn and cruise control.
Pilot joystick control provides comfortable precise blade operation.

Semi-Universal Blade

SU blade combines the excellent penetration of the S blade and the high production capacity of the U blade.
Designed for superior load retention and penetration in tightly packed materials.
L-shaped push arms bring the blade closer to the machine, providing excellent maneuverability, balance and blade penetration.
Blades feature a strong box section design, made from high tensile strength steel to stand up to the most severe applications.

Undercarriage

Undercarriage is provided by China industry expert ensures high reliability and resistance to wear.
Carrier rollers track rollers and idle rollers are all maintenance free.
Planetary final drive design delivers increased torque ratio for higher transmission effi ciency and lower maintenance cost.
Durable final drive bearings and multiple wet disc brakes provide reliability, reduce system heat and extend overall life.

Structures

Machine structures are analyzed using Finite Element Analysis (FEA) and On Machine Stress Analysis (OMSA) to identify and protect high stress areas.
Advanced structure welding technique, relieving welding stress.

Cat ® Product Link™

Cat® Product Link™ will support your business, and accurately convey information of the equipment to relevant personnel in a timely and effective manner for your better equipment management.

Model
Model	816D
Configuration	STD	DS	CH	LGP	FR	Angle Blade
Main Specifications
Operating Weight with ROPS
Operating Weight (w. SU blade, Ripper)	18,230kg	19,760kg	18,490kg	19,490kg	19,910kg	17,140kg
Ground Pressure (GB/T 30965)	66.8kPa	34.8kPa	61.8kPa	31.1kPa	66.9kPa	66.8kPa
Minimum Ground Clearance (Excludes Grouser Height)	410mm
Gradeability	30°
Engine
Engine Model	WD10G178E25
Advertised Power (ISO 14396)	131kW
Rated Speed	1,850r/min
Powertrain
Transmission Type	Dual-path, closed loop electronically controlled hydrostatic drive system
Travel Speeds - Forward and Reverse	Infinitely variable speeds 0-10 km/h
Steering and Brake	hydrostatic steering, wet, multi-disc brake
Implement Hydraulic
Type	center close, pilot control
System Pressure	19MPa
Pump Type	Gear pump
Blades
Blade Type	SU/S	LGP	LGP	U	SU Forestry/S Forestry	Angle Blade
Blade Capacity (ISO 9246)	4.3m³/3.5m³	3.4m³	5.6m³	3.4m³	6m³/5.8m³	3.5m³
Blade Width (w/End Bit)	3,180mm/3,590mm	4,410mm	3,580mm	4,410mm	3,180mm/3,590mm	3,970mm
Blade Height	1,240mm/1,165mm	1,000mm	1,400mm	1,000mm	1,625mm/1,625mm	1,090mm
Blade Lifting Height	1,041mm	1,055mm	1,041mm	1,055mm	1,041mm	1,067mm
Blade Digging Depth	430mm	470mm	430mm	470mm	430mm	430mm
Blade Tilt Height (Middle Hole)	455mm	470mm	508mm	470mm	455mm	455mm
Blade Weight (w/o Push Arm)	1,390kg	1,540kg	1,640kg	1,540kg	1,555kg	1,450kg
Minimum Turning Radius	3,610kg	3,740kg	3,610kg	3,740kg	3,610kg	3,610kg
Single Shank Rippers
Type	N/A
Maximum Penetration (Shank Pinned in the Top Hole)	N/A
Maximum Clearance Under Tip (Shank Pinned in the Bottom Hole)	615mm	N/A	615mm	N/A	615mm	N/A
Ripper Weight	N/A
Undercarriage
Track Shoe Width	510mm	950mm	560mm	N/A	560mm	N/A
Track Shoes Number (Each Side)	37	42	37	42	37	37
Track Rollers Number (Each Side)	6	7	6	7	6	6
Carrier Roller Number (Each Side)	2	2	2	2	2	2
